Rebar Tying Tool XGT®
TR001G40V Max
Model TR001G is a rebar tying tool powered by a 40V Max XGT Li-Ion battery.
Adopting a high voltage XGT battery and ø1.6mm thick wire, the tool delivers high tying strength and speed. Designed specifically for annealed wire. Easy loading of tying wire. Compatible with a wide range of rebar combinations.
- Available version(s)
- General
- Technical info
- Related Products
- Parts diagram
- Dust Extraction
- Additional info
- Support
Available version(s)
1 Available version
TR001GZ
Rebar Tying Tool XGT®,
Model TR001G is a rebar tying tool powered by a 40V Max XGT Li-Ion battery.
General
Technical info
Technical specifications
-
Nominal Battery Voltage40 V
-
Brushless Motor
-
Sound Power Level (LWA)88 dB(A)
-
Sound Pressure Level (LpA)80 dB(A)
-
Noise Uncertainty (K Factor)3 dB(A)
-
Vibration Level (3 axes)≤ 2,5 m/s²
-
Vibration Uncertainty (K Factor)1,5 m/s²
-
Tool weight with battery3,3 - 4,5 kg
-
Product net weight2,6 kg
-
Product Dimensions (L x W x H):375 x 113 x 331 mmProduct dimensions are stated with a battery / batteries, if they affect the overall dimensions of the product.- CXT® machines with 2,0Ah batteries- LXT® machines with 6,0Ah batteries- XGT® machines with 4,0Ah batteries
-
Maximum tying capacity 2 rebars25 x 29 mm
-
Maximum tying capacity 3 rebars(19 x 19) x 25 mm
-
Maximum tying capacity 4 rebars(16 x 16) x (16 x 16) mm
-
Wire diameter1,6 mm
Symbols:
Anti-restart function
