Available version(s)
General
User benefits
- Lightweight for reduced operator fatigue
- Reverse rotation system frees the blade when it is jammed by thick branches
- Constant speed control maintains constant speed under load
- Electric brake for increased productivity and operator safety
- Non-angle adjustable hedge trimmer head
- Soft grip provides comfortable and sure grip
- Main power switch automatically turns off for user protection under certain conditions
- Battery protection circuit protects against overloading, over-discharging and over-heating
Technical info
Technical specifications
-
Nominal Battery Voltage18 V
-
Brushless Motor
-
Voltage LXT
-
Impacts per Minute (IPM)2000 / 3600 / 4400 min⁻¹
-
Max Cutting Capacity23,5 mm
-
Continuous Use 18V / 6.0 Ah Battery180 / 80 / 55 min
-
Length Of Blade600 mm
-
Sound Power Level (LWA)93,5 dB(A)
-
Sound Pressure Level (LpA)82,5 dB(A)
-
Noise Uncertainty (K Factor)3 dB(A)
-
Vibration Level (3 axes) at Front Handle3,8 m/s²
-
Vibration Level (3 axes) at Rear Handle2,7 m/s²
-
Vibration Uncertainty (K Factor)1,5 m/s²
-
Tool weight with battery3,7 - 4,1 kg
-
Product Dimensions (L x W x H):2050 x 230 x 178 mm
Product dimensions are stated with a battery / batteries, if they affect the overall dimensions of the product.
- CXT® machines with 2,0Ah batteries
- LXT® machines with 6,0Ah batteries
- XGT® machines with 4,0Ah batteries -
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion)Li-ion
-
Product net weight3,4 kg
Symbols:
Brake
Reversing
Mechanical 3-Speed
Constant speed
