New
Angle Drill
DA3011450 W • 0 – 2 400 min⁻¹
The compact size allows you to work in difficult places
Angle drill with only 93 mm angle measure. Ideal for working in confined spaces. The narrow design of the handle ensures excellent handling. Paddle switch with speed limiting dial to minimize over-tightening of fasteners.
- Available version(s)
- General
- Technical info
- Related Products
- Parts diagram
- Dust Extraction
- Additional info
- Support
Available version(s)
2 Available version
DA3011/1
Angle Drill
The compact size allows you to work in difficult places
DA3011/2
Angle Drill
The compact size allows you to work in difficult places
General
User benefits
- Double insulated
- Compact and lightweight design
Technical info
Technical specifications
-
Continuous Input Power450 W
-
No load speed0 - 2400 min⁻¹
-
Max. Drilling Diameter in Wood25 mm
-
Max. Drilling Diameter in Steel10 mm
-
Drill Chuck Capacity1,5 - 10 mm
-
Power Supply Cord2,5 m
-
Sound Power Level (LWA)92 dB(A)
-
Sound Pressure Level (LpA)81 dB(A)
-
Noise Uncertainty (K Factor)3 dB(A)
-
Weight Without Cable1,6 kg
-
Product Dimensions (L x W x H):282 x 61 x 93 mmProduct dimensions are stated with a battery / batteries, if they affect the overall dimensions of the product.- CXT® machines with 2,0Ah batteries- LXT® machines with 6,0Ah batteries- XGT® machines with 4,0Ah batteries
-
Angle length93 mm
-
Drilling Capacity Wood (Self-feed bit)50 mm
-
Vibration Level, Drilling into metal≤ 2,5 m/s²
-
Vibration Uncertainty (K Factor), Drilling into metal1,5 m/s²
-
Product net weight1,4 kg
Symbols:
Double Insulation
Variable Speed
Reversing
Keyless chuck
